1600 cfm Tier4 Final Diesel Compressor (ZACY)
The new standard for diesel-driven oil-free air.
Our 100% oil-free air compressors offer exceptional energy efficiency and reliability. Designed to meet the unique needs of diverse sectors and critical applications, our Tier 4 Final compressors maintain the safe operation of equipment and the quality of products, while delivering reduced fuel consumption, lower maintenance costs and enhanced uptime.
| Capacity | 1600 cfm |
|---|---|
| Min Operating Temp (°C) | -15 °F (-26 °C) |
| Max Operating Temp (°C) | 110 °F (43 °C) |
| Approach Temperature (Discharge) | -11 °C (12 °F) |
| Min Pressure (psig) | 50 psi (4.826 bar) |
| Max Pressure (psig) | 150 psi (10.342 bar) |
| Nominal Shaft Power | 617 hp (460 kw) |
| Length (ft) | 20 ft (6.1 m) |
|---|---|
| Width (ft) | 7.5 ft (2.29 m) |
| Height (ft) | 8.5 ft (2.59 m) |
| Gross Weight (kg) | 21,500 lbs (9,752 kg) |
| Gross Fuel (l) | 324 US gal (1,230 liters) |
