400 Ton Chiller
Air-Cooled and Water-Cooled Industrial Chiller Rentals
400 Ton Chiller - Environmentally friendly Aggreko rental chillers are designed and built for harsh industrial environs. They provide supplemental, temporary or emergency cooling for high-volume applications — such as at refineries or power stations.
| Rating | 400 ton |
|---|---|
| Air or Water Cooled | Air-Cooled |
| Min Leaving Fluid Temp (°C) | 60 |
| Max Leaving Fluid Temp (°C) | -18 |
| Min Flow Rate (lpm) | 1817 |
| Max Flow Rate (lpm) | 5451 |
| Frequency (Hz) | 60 Hz |
| Length (m) | 13.79 |
|---|---|
| Width (m) | 2.44 |
| Height (m) | 2.44 |
| Gross Weight (kg) | 11349.34 |
| Net Weight (kg) | 11349.34 |
| Lifting - Forklift Pockets | Yes |
Features
- 3 phase and Earth Electrical connections, no neutral cable required
- Standard camlock fluid fittings and valves on inlet and outlet ports for quick hose connection
- Designed to "plug and play" with all Aggreko TC ancillary devices (hoses, pumps, manifolds, heat exchangers, buffer tanks, etc.)
- 480V/3ph/60Hz voltage range
- Wide operating range, Condenser Fan Guards provide protection against accidental site damage, Full CE Design Compliance
- Overhead lift with spreader bars and available forklift pockets
- 24/7 Aggreko Remote Monitoring
Benefits
- Fitted with state of the art electronic controllers for accurate and reliable operation
- Easy to read and adjust, the unit control panel includes inlet and outlet temperatures, system pressure and set point parameter
- Adaptive Controls maintain very stable temperature control under all system conditions (variances in ambient temperature, flow rate changes, etc.)
- Proactive monitoring by Aggreko’s Remote Operations Center (ROC) to ensure maximum uptime. Customer monitoring & notifications available through Aggreko’s ARM app and portal.
