80 kW Uninterruptible Power Supply (UPS) System

Scalable, modular UPS for mission critical availability

Aggreko's modular, online double conversion 80 kW UPS protects critical data and equipment from power-related issues, while supplying clean and reliable network grade power.

The 80 kW UPS can be configured with a fully redundant power module and battery modules. Should one module fail, the remaining modules smoothly take over the load. The power modules are independent and can be hot swapped without risk to the critical load.

Delivered Power 80 kVA / 80 kW
Energy Capacity 80 kVA / 80 kW
Standby Rating 80 kW
AC Voltage Allowable Range 208 / 120V, 50 / 60 Hz auto-sensing
AC INPUT Voltage Range 121–253 VAC* (L-L), 40-70 Hz
AC Output, Voltage, Frequency 208 / 120V
Maximum Load (All Phases) Before Generator Start Command (kW) Configurable based on application
Nominal Voltage ± 120V
Charge Current 32A
Length (ft) 3.61 ft
Width (ft) 1.97 ft
Height (ft) 6.59 ft
Gross Weight (lbs) 657 lbs

Benefits

  • Provides more real capacity for high density loads
  • Modularity makes it easy to add modules and increase capacity when power or runtime requirements change
  • Transfers critical load from UPS power to utility power with front mounted MBP switch
  • 10-inch display provides operational data visibility, including status and alarms, enhancing reliability
  • Provides maximum installation flexibility

Features

  • Unity output power factor
  • Scalable
  • Modular static switch
  • Maintenance bypass
  • Large touchscreen LCD display
  • Dual or single utility input

Explore our Modular M90 80 kW UPS Solutions

Discover how the M90 80 kW UPS provides scalable and modular protection for critical loads in high-demand environments. Ideal for mission-critical applications, this UPS system delivers clean, reliable power with flexible configurations that allow easy module expansion as needed. With a 10-inch touchscreen display and modular static switch, the M90 80 kW ensures real-time operational data visibility and maximum installation flexibility, safeguarding your essential equipment and data.
