AG-4 400 Ton Cooling Tower

Modular and Heavy Industrial Rental Cooling Towers

Temporary AG-4 400 Ton Cooling Tower - The AG series cooling towers are a modular cooling tower and are known as the workhorse of the rental cooling tower industry. This 400 ton cooling tower with modular design can be used independently or interconnected with multiple AG series cooling towers to achieve any heat load. Each AG series cooling tower has a folding substructure and an access platform. The permanently attached substructure reduces installation time and can be adjusted to either 5 foot or 8 foot elevations. The access platform serves as an elevated walkway to the external sump and control panel. The thermal performance of the GT series cooling towers are CTI Certified and are available in both standard duty and also in the HD version for those dirty water applications.

AG-4 400 Ton Cooling Tower

Air Delivery Type

Forced Draft

Fan Motor Size

4 x 7.5 horsepower

Fan Speed Control

Optional

Full Load Amps

30 Amps

Inlet Connection Size hot

1 x 12" Flange

Make-up water connection

2" FNPT

Nominal Capacity

400 tons

Nominal Water Flow

1200 GPM

Outlet Connection Size (cold)

1 x 12" Flange

Volts/Phase/Hz

480/3/60

Height (ft)

11-0"

Length (ft)

12-0"

Operating Weight

15180 lbs

Shipping Weight

8800 lbs

Substructure Height

5-0" / 8-0" / 14-0"

Width (ft)

12-0"

Features

  • Modular Design
  • Elevated Cold Water Basin
  • External Sump
  • Folding/Telescoping Substructure
  • CTI Certification

Benefits

  • Multiple units can be interconnected to form a single cooling tower capable of achieving any capacity
  • The elevated cold water basin makes draining the cold water long distances without the need for additional pumps
  • Sump screens and float valves are accessible external of the tower
  • The substructure design makes installation safer and more efficient
  • CTI Certification ensures users  the thermal capacity is properly represented
